Flatten¶
Riferimento
- Modalità:
Modalità Modifica
- Menù:
Flatten selected vertices onto a plane.
The operator calculates a target plane and moves vertices toward it while preserving their relative positions along the unlocked axes.
Opzioni¶
- Fattore
Strength of the flatten operation.
A value of
1fully flattens the selection onto the target plane, while lower values partially move vertices toward the plane.- Method
Method used to determine the flattening plane.
- Best Fit:
Calculates a plane that best fits the selected vertices.
- Normale:
Derives the plane from the averaged normals of the selected faces.
- Vista:
Uses a plane perpendicular to the current view direction.
- Blocca
Prevents movement along selected axes while flattening.
This can be used to constrain the flatten operation to specific directions.
