Viewer Node – Вузол «Оглядач»

The Viewer node.

Using a Viewer node a geometry, and optionally a field evaluated it, can be displayed in the Spreadsheet Editor. A node can be connected with a Viewer node by pressing Shift-Ctrl-LMB, while hovering the mouse over it, just like in the Compositor.

Inputs – Уводи

Geometry – Геометрія

Geometry that will be displayed in the Spreadsheet.

Value – Значення

Field to be evaluated on the geometry. The type for this value is chosen automatically when the keyboard shortcut to link an output is pressed. However, if the type must be adjusted manually, it is available in the node editor Sidebar.

Properties – Властивості

Цей вузол наразі немає властивостей.

Outputs – Виводи

Цей вузол немає жодних виводів.
